Dynojet 250i: Control Panel Interface Upgrade (S/N 201xxxx) - Manual (Page 8)

6
10. Remove the four bolts holding the Power Distribution assembly and remove the old Power
Distribution assembly.
11. Disconnect the red battery cable from the starter and the black battery cable from the ground
connection. Disconnect the starter solenoid wire also. All wires should be removed from the starter.
Disconnect the red and black wires that go into the black box on the back wall of the drum module.
Remove these
bolts
Remove
these wires
Remove Red
and Black wires
at other end
Disconnect
Yellow/Black
twisted wire
