Dynojet 250i: Control Panel Interface Upgrade (S/N 201xxxx) User Manual
Page 25
23
41. Route the cables to the cable support bracket as shown. Cable tie as shown. Make sure all of the
cables clear any moving components. Only connect the positive terminal on the battery at this time. If
this is the first time you have installed a battery in this dyno refer to the dyno install guide for
instructions on installing the battery hold down bracket.
Cable Support
Bracket
