High Pressure Blower Installation Guide
H I G H P R E S S U R E B L O W E R
Introduction
2
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
INTRODUCTION
The high pressure blower supplies air to cool the bike’s engine. This section will walk
you through the blower installation procedures on the model 200i and 250i
motorcycle dynos.
To prevent possible injury, place the breaker inside the power distribution
enclosure to the off position and unplug the dyno. Refer to Figure 1 for breaker
location.
Figure 1: Model 200i/250i Breaker Location
power cord
breaker
power distribution enclosure
