High Pressure Blower Installation Guide
A-1
A
P P E N D I X
A
M
ODEL
200/250 B
LOWER
I
NSTALLATION
This appendix provides instructions for installing the high pressure blower assemblies
to the model 200/250 motorcycle dynamometer (dyno). To ensure safety and
accuracy in the procedures, perform the procedures as they are described.
This section will walk you through the blower installation procedures and adjusting
the extension arm assembly when a power carriage is installed.
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
PARTS LIST
The following table lists all of the parts included in the High Pressure Blower Retrofit
Installation kit (P/N 77020002). Check your kit against the parts listed to make sure
you have received all of the parts. If any part is missing, contact Dynojet Technical
Support.
part number description quantity
61328101 High Pressure Blower Assembly 2
63413002 Mounting Bracket and Extension Arm Assembly 1
26215520 Washer, 1.87 x 1.25 ID x .12 Thick (Poly Washer) 2
36582477 Bolt, 3/8"-16 x 1.5", Hex 4
36488100 Nut, 3/8"-16, Nylock 4
36932100 Washer, 3/8", Splitlock, Stl 4
