Gigabit Ethernet Metro-Switch Board and Firmware Users Manual
DSS NETWORKS, INC. Version: 1.14g Page: 8
Part Number 182614
Model 8261
Description 12-port Compact PCI PICMG 2.16 compliant switch
# Copper ports 12 (10/100/1000 Base T)
# Fiber ports 0 (without fiber uplinks)
Switch type Multilayer (L2 – L7)
Note: Please note that copper ports 10 and 11 are not active when
fiber ports are used.
3. FEATURES
The Metro-Switch adapter offers the following key features:
• 12-port full-duplex Gigabit Ethernet interfaces routed to 2.16 backplane or rear
I/O
• Optional support for 2 multimode or singlemode fiber links (850nm MM or
1310nm SM LC)
• Sustained aggregate throughput of 24 Gbps (3 GB)
• Frame processing rate of up to 32 million frames per
• Onboard RISC management processor and EEPROM configuration
• 4 multi-function LEDS per port (TX, RX, LINK, Signal Quality)
• 32-bit, 66 MHZ PCI interface
• Onboard RS232 (RJ-11 jack) for serial port console support
• Remote network access via Telnet
• Basic hot-swap support for hardware connection layer
• Installs in CompactPCI PICMG 2.16 compliant system chassis
• Optionally installs in standard Compact PCI PICMG 2.0 R3.0 chassis
• Available with 12-port rear I/O transition module
• Ideal solution for CompactPCI rackmount embedded systems
• Utilizes single 5V power from JN1/JP1 PCI connector
• Provides power regulators onboard for power distribution (3.3V, 2.5V, 1.25V)
• Complies with all PCI revision 2.2 mechanical and electrical requirements
• Fully IEEE 802.3z, IEEE 802.3ab, 802.3u and IEEE 1386 compliant
• Compatible with all 10/100/1000BaseT hubs, switches and routers
• Operates as standalone Layer 2 switch or fully managed L3/multiplayer switch
• Jumbo frame support for up to 9K
• 802.3x full duplex flow control
