Page 18
Gigabit Ethernet Metro-Switch
Board and Firmware Users Manual
DSS NETWORKS, INC.
Version: 1.14g
Page: 18
Board Connectors pin diagram J5
CPCI
Connector J5
Signal Name
CPCI
Connector J5
Signal Name
A1 MDIB_P-9
B1
MDIB_N-9
A2 MDIA_P-9
B2
MDIA_N-9
A3 MDIB_P-10
B3
MDIB_N-10
A4 MDIA_P-10
B4
MDIA_N-10
A5 MDIB_P-11
B5
MDIB_N-11
A6 MDIA_P-11
B6
MDIA_N-11
A7 MDIB_P-12
B7
MDIB_N-12
A8 MDIA_P-12
B8
MDIA_N-12
A9 LP13-DB_P
B9
LP13-DB_N
A10 LP13-DA_P
B10
LP13-DA_N
A11 LP14-DB_P
B11
LP14-DB_N
A12 LP14-DA_P
B12
LP14-DA_N
A13 LP15-DB_P
B13
LP15-DB_N
A14 LP15-DA_P
B14
LP15-DA_N
A15 LP16-DB_P
B15
LP16-DB_N
A16 LP16-DA_P
B16
LP16-DA_N
A17 LP17-DB_P
B17
LP17-DB_N
A18 LP17-DA_P
B18
LP17-DA_N
A19 LP18-DB_P
B19
LP18-DB_N
A20 LP18-DA_P
B19
LP18-DA_N
A21 LP19-DB_P
B19
LP19-DB_N
A22 LP19-DA_P
B19
LP19-DA_N
C1 GND
D1
MDID_P-9
C2 GND
D2
MDIC_P-9
C3 GND
D3
MDID_P-10
C4 GND
D4
MDIC_P-10
C5 GND
D5
MDID_P-11
C6 GND
D6
MDIC_P-11
C7 GND
D7
MDID_P-12
C8 GND
D8
MDIC_P-12
C9 GND
D9
LP13-DD_P
C10 GND
D10
LP13-DC_P
C11 GND
D11
LP14-DD_P
C12 GND
D12
LP14-DC_P
C13 GND
D13
LP15-DD_P
C14 GND
D14
LP15-DC_P
C15 GND
D15
LP16-DD_P
C16 GND
D16
LP16-DC_P
C17 GND
D17
LP17-DD_P
C18 GND
D18
LP17-DC_P
C19 GND
D19
LP18-DD_P
C20 GND
D20
LP18-DC_P
C21 GND
D21
LP19-DD_P
C22 GND
D22
LP19-DC_P
E1 MDID_N-9
F1
GND
E2 MDIC_N-9
F2
GND
