5.4 CPCI CONNECTOR PIN/SIGNAL DEFINITIONS
The MetroSwitch models use the J1, J3 and J5 Compact PCI connectors as shown in
the following diagrams. Connectors J2 and J4 are not used.
Board Connectors pin diagram J1
CPCI
Connector J1
Signal Name
CPCI
Connector J1
Signal Name
A1 EARLY_5V
B1
-12V
A2 P_TCK
B2
EARLY_5V
A3 P_INTA_N
B3
INTB#
A4 P_IPMB_PWR
B4
P_HEALTHY_N
A5 NC
B5
RESERVED
A6 P_REQ_N
B6
GND/PCI_PRSNT#
A7 P_AD30
B7
P_AD29
A8 P_AD26
B8
GND
A9 P_CBEN3
B9
P_IDSEL
A10 P_AD21
B10
GND
A11 P_AD18
B11
P_AD17
A12 NC
B12
NC
A13 NC
B13
NC
A14 NC
B14
NC
A15 EARLY_3V
B15
P_FRAME_N
A16 P_DEVSEL_N
B16
P_PCIXCAP
A17 EARLY_3V
B17
P_IPMB_SCL
A18 P_SERR_N
B18
GND
A19 EARLY_3V
B19
P_AD15
A20 P_AD12
B20
GND
A21 EARLY_3V
B21
P_AD9
A22 P_AD7
B22
GND
A23 EARLY_3V
B23
P_AD15
A24 P_AD1
B24
EARLY_5V
A25 EARLY_5V
B25
REQ64#
C1 P_TRST_N
D1
+12V
C2 P_TMS
D2
P_TDO
C3 INTC#
D3
EARLY_5V
C4 EARLY_VIO
D4
INTP
C5 P_RST_N
D5
GND
C6 EARLY_3V
D6
P_PCICLK
C7 P_AD28
D7
GND
C8 EARLY_VIO
D8
P_AD25
C9 P_AD23
D9
GND
C10 EARLY_3V
D10
P_AD20
C11 P_AD16
D11
GND
C12 NC
D12
NC
C13 NC
D13
NC
C14 NC
D14
NC
C15 P_IRDY_N
D15
P_BDSEL_N
C16 EARLY_VIO
D16
P_STOP_N
