5.3 BOARD LED INDICATORS
There are 12 LED arrays marked “P0” thru “P11” on the front panel. Each port array has
4 green LEDS and their meaning is described in the following table:
Port LED Arrays (P0 – P11) Function Table (from left to right)
Gigabit Switch
Model LED # 1
Green LED # 2
Green LED #3
Yellow LED #4
Yellow
8260/8261 Link TX RX Quality*
Note: The Quality LED is only available for ports in 1000-Base-T copper mode.
There is also a single LED Array containing a row of 3 LEDS (2 Yellow, 1 Green)
described in the following table:
Processor LED (LED1) Function Table (left to right)
Gigabit Switch
Model LED # 1
YEL LED # 2
YEL LED #3
Green
8260/8261 Warn LinkSt RUN
Note: After power on and during normal operation, the green “RUN” LED should
always blink at a slow steady heartbeat pace of about once per every 2 seconds.
