FFP “GIMASK” table bit map description:
Additional notes: See the following Broadcom documents for further details regarding
the programming of the FFP:
Programmer's
Reference Guide
569x-PG101-R
StrataXGS(tm)
BCM5690/BCM5691/BCM5692/BCM5693
Application Note 5690-AN100-R
BCM5690 Fast Filtering Processor
Application Note
Application Note 5690-AN900-R
BCM5690 Application Note -
StrataXGS - Traffic Mirroring
9.1.31 ‘GIRULE SET’ COMMAND
The ‘girule set’ command is used to setup the “GIRULE” tables for the FFP processor.
The command takes seven numeric arguments. The first argument is the ‘link’ index (0-
11) and the second argument is the ‘rule’ index (0-63). The third argument is the table
entry index (0 – 11). The last 4 arguments are the data bytes comprising the 32-bit
FMASK(8)
FMASK(7)
FMASK(6)
FMASK(5)
FMASK(4)
FMASK(3)
FMASK(2)
FMASK(1)
RSVD OUTPUTMODMASK(5) RSVD(7) EGRMASK(5)
PKTFORMAT
MASK(4)
RSVD OUTPUTMOD(5) U OUTPUTPORT(5) TOS_P(3) DIFFSERV(6)
IEEE802-
DOT1PRI
NOTDEFINED DATAOFF-8 DATASOFF=7 DATAOFF-6 DATAOFF-5 DATAOFF-4 DATAOFF-3 DATAOFF-2 DATAOFF-1
R
RULES-SIZE(8) RULES-START(7) NOMATCHACTION(16)
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16 15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
ADDR-LIMIT 0x07g0.000B:table bit 383
ADDR-BASE 0x07g0.0000:table bit 0
