Figure 24

Figure 25

Figure 26

Figure 27

LOCK TAB

THEN PUSH IN LOCK TAB

Figure 28

Figure 29

Hydraulic jack

Gasket scraper

Jack stands or Wheel ramps

3/8" Drill motor

Oil drain pan

Fine cut flat file

3/8" drive ratchet wrench

3/8" drive, 4" extension

8mm, 10mm, 13 mm, Sockets

Wet or Dry sand paper

Grease or petroleum jelly

Needle nose pliers

Torque wrench

Small flat screwdriver

Funnel

TOOL LIST

PARTS LIST

Spring, Red

Pressure regulator

1

Spring, Green

1-2 capacity modulator valve

1

Spring, Yellow

1-2 capacity modulator valve

1

Spring, blue

2-3 accumulator

1

Spacer, gold

2-3 accumulator

1

Seal ring

2-3 accumulator

1

Seal ring

2-3 accumulator

1

Drill

1/8"

1

Alignment pin

M6 X 40mm

2

Screw

M4 X .7 X 10mm

1

Nut

M6 hex

2

Gasket

Plate to case

1

Gasket

Plate to valve body

1

Gasket

Oil pan

1

Gasket

Oil filter

1
