Alumax W2 CW User Manual
Page 9
30 3/4”
30 3/4”
48 = 22 1/16”
or
60 = 28 9/16”
48 = 22 1/16”
or
60 = 28 9/16”
LEFT SIDE INSTALLATION
RIGHT SIDE INSTALLATION
INSTRUCTION MANUAL
9
4
CUT THE “U” CHANNEL
The “U” channel needs to be cut according to the dimensions
in the table. Make sure the correct angles is kept.
4a
Model
Fix Panel
Return Panel
48
22 1/16”
30 3/4”
60
28 9/16”
4
5
4
5
