Alumax W2 CW User Manual
Page 8
1
INTERIOR
SHOWER SIDE
3e
3g
INSTRUCTION MANUAL
8
3
WALL JAMB INSTALLATION (CONTINUED)
24
3d
3f
Insert one drop of silicone in each hole in the wall before
inserting the wall plug (x8).
Apply silicone at the bottom of the wall jamb on the side that
goes against the wall as illustrated.(x2)
Reposition the wall jamb on the line marked previously.
Ensure verticality with the level. Screw the wall jamb on to the
wall using the screws 1 3/8’’ (x8).
Apply silicone on the inside of the wall jamb as illustrated.
3d
3e
3f
3g
26
