Alumax W2 CW User Manual
Page 11
5d
5e
5f
INSTRUCTION MANUAL
11
5f
5d
5e
Place U-Channels temporarily on the bottom of panel (12).
Make sure the “U” channels are placed correctly
Install both corner clips as illustrated. Remove the bracket from the
glass mount plate and install the glass mount plat on the return panel.
5
LOCATATION OF THE U CHANNEL (CONTINUED
12
4
5
4
17
18
