Alumax W2 CW - Manual (Page 15)

INTERIOR
SHOWER SIDE
CERAMIC TILE INSTALLAITON, USE A
BIT FOR CERAMIC TILE.
9a
9e
9b
9d
INTERIOR
SHOWER SIDE
INTERIOR
SHOWER SIDE
9c
INSTRUCTION MANUAL
15
9 BOTTOM GUIDE
Place door panel (10) inside shower to sim-
plify following installation procedures. place the
panel on a cushioned surface, such as a towel
or cardboard, to prevent damage either to the
panel or the base.
d n a l e n n a h C - U f o e g d e o t e d i u g m o tt o b e c a l P
center the front channel of the bottom guide to
the center of U-Channel.
Once in place mark hole location and remove
bottom guide.
Drill with 1/8” drill bit in marked location, then
apply a drop of silicone in hole.
Reposition bottom guide and secure in place.
Top with screw cap.
!
CARBOARD OR TOWEL
TO PROTECT
10
!
9a
9b
9c
9d
9e
