10a 10b – Alumax W2 CW User Manual
Page 16
COVER THE PLIER’S TEETH BEFOREHAND TO AVOID
SCRATCHING THE ALUMINUM PARTS.
21
12
4
10a
10b
INSTRUCTION MANUAL
16
Reinstall panel as well as the return
panel, corner clips and glass mount plate.
Be sure to level panels and align panel
edge with end of bottom guide.
Lock into position by clamping the wall
jambs and expanders with pliers.
10a
10b
10
PANEL INSTALLATION
11
10
INTERIOR
SHOWER SIDE
12
PLACE GASKET IN BOTTOM GUIDE
BEFORE INTALLING FIX PANEL.
INTERIOR
SHOWER SIDE
