INSTRUCTION MANUAL
10
5
LOCATATION OF THE U CHANNEL
5c
5a
5b
Place U-Channels temporarily on the bottom of return panel (11).
Slide the return panel pre-assembled with expander (2) and gasket (3) into the wall jamb (1).
Level the glass panel assembly with the wall jamb. Lock into position by clamping the wall jamb and expander with a plier.
COVER THE PLIER'S TEETH
BEFOREHAND TO AVOID
SCRATCHING THE
ALUMINUM PARTS.
