Identifying the Parts

Ui EJECT switch

(p.9)

071 REMOTE LANC C control jack

C stands for Local Application Control Bus
System. The C control jack is used for
controlling the tape transport of video
equipment and peripherals connected to it.
This jack has the same function as the jack
indicated as CONTROL L or REMOTE.

01 Cassette compartment

(p.9)

01 Grip strap

(p.l4)

0 (headphones) jack

(p.l7)

] RFU DC OUT (RFU adaptor DC output)

jack (p.f6)

S VIDEO jack (CCD-TR910 only)

(p.l6)

MIC jack (PLUG IN POWER)

Connect an external microphone (not
supplied). This jack also accepts a "plug-in
power" microphone.

VIDEO/AUDIO jacks

(p.l6)

The jack changes automatically, allowing it
to function as both an input jack and an
output jack.
