Sony STR-DB940 - Manual (Page 8)

Video Component Hookups
0
O
9T
3*
<0
tt
9
3
o
3
»
3
cr
Required cords
Audio/video cords (not supplied)
When connecting a cord, be sure to match the color-coded pins to
the appropriate jacks on the components
Yellow (video)
White (L/audio) White (L/audio)
Red (R/audio) Red (R/audio)
iadks for connectitig video €Oiti|»oiient5
Connect a To the
TV or satellite tuner TV/SAT jacks
VCR VIDEO 1 jacks
Additional VCR VIDEO 2 jacks
DVD or LD player DVD/LD jacks
TV monitor^* MONITOR VIDEO OUT jack
Camcorder or video game VIDEO 3 INPUT jacks on the
front panel
For STR-DB940, you can display the SURROUND, LEVEL,
EQUALIZER parameters by pressing the ON SCREEN button
on the remote
Note OR video comfmnent hookutm
You can connect your TV's audio output jacks to the TV /
SAT AUDIO IN jacks on the receiver and apply sound
effects to the audio from the TV In this case, do not
connect the TV's video output jack to the TV/ SAT VIDEO
IN jack on the receiver If you are cormecting a separate
TV tuner (or satellite tuner), connect both the audio and
video output jacks to the receiver as shown above
9 When using the S-video jacks instead of the video jacks
Your monitor must also be cormected via an S-video jack S-video
signals are on a separate bus from the video signals and will not
be output through the video jacks
8
