Sony DCR-TRV510 - Manual (Page 128)

6 Click [Detail].
The Digital Still Camera Settings dialog box appears.
Digital Still Cameia Settings
7 Make the desired settings, and click [OK].
Baud Rale; Normally 115200 bps. A slower rate may be used if serial
communications problems occur.
Serial Port; Select the PC port that corresponds to the connection in step
2. See the PC operating manual for the port number.
Close the Digital Still Camera Settings dialog box.
8 Click [OKh
The settings are refreshed and the dialog box closes.
Using the Firis^T|me,
■o or JrtiWtt'dirt'»«- 11
1 Check the connections and insert the Memory Stick containing
the desired image in the digital still camera.
2 In the File menu, point to Connections, and click Digital Still
Camera.
The Digital Still Camera folder icon appears in the folder list, and images
in the folder appear in the View Area.
Digital Still Camera folder i
20
‘
