Sony DCR-TRV510 User Manual
Digital video camera recorder, Sony
Attention! The text in this document has been recognized automatically. To view the original document, you can use the "Original mode".
SONY.
3-866-124-11 (1)
Digital
Video Camera
Recorder
Operating Instructions
Before operating the unit, please read this manual thoroughly,
and retain it for future reference.
Owner's Record
The model and serial numbers are located on the bottom. Record the
serial number in the space provided below. Refer to these numbers
whenever you call upon your Sony dealer regarding this product.
Model No. DCR-TRV-
Serial No. __________
Model No. AC--
Serial No. _____
Digital 8
DCR-TRV510l^
Handycam
(
j
3
InfoLITHIUM
©1999 by Sony Corporation
