Tomei Powered TECHNICAL TRAX/ ADVANCE LSD - Manual (Page 23)

KAA
[PLATE LOCATION FOR REBUILDS]
[EXAMPLE: INCREASING INITIAL TORQUE]
↓
G
[PLATE LOCATION FOR REBUILDS]
2 2
- -
2 2
①
②
NO. OF DISCS
INCREASED INITIAL TORQUE STOCK INITIAL TORQUE→
NO. OF PLATES i.e. Increased Torque (kg・m)
LOCATION
11.0-13.0
TYPE
SPRING DISC (TOOTHLESS)
6 6 ⑤
SPRING DISC (OUTER TEETH)
SPRING DISC (INNER TEETH)
FRICTION DISC (OUTER TEETH)
FRICTION DISC (INNER TEETH)
4 2 + 2(0.1mm thicker) 13.0-15.0 ④
③
② ③ ⑤ ④ ⑤ ④ ⑤ ④ ⑤ ④ ⑤ ③ ⑤ ②
② ③ ⑤ ④ ⑤ ④ ⑤ ④ ⑤ ④ ⑤ ③ ⑤ ②
23
[PLATE LOCATION FOR REBUILDS]
[EXAMPLE: INCREASING INITIAL TORQUE]
↓
6 6 ④
2 2
- 2
②
③ SPRING DISC (OUTER TEETH)
- -
NO. OF DISCS
INCREASED INITIAL TORQUE
NO. OF PLATES
TYPE
16.0-18.0
10.0-12.0
i.e. Increased Torque (kg・m)
LOCATION
STOCK INITIAL TORQUE→
8 6 ⑤
① SPRING DISC (TOOTHLESS)
FRICTION DISC (OUTER TEETH)
FRICTION DISC (INNER TEETH)
SPRING DISC (INNER TEETH)
② ⑤ ④ ⑤ ④ ⑤ ④ ⑤ ④ ⑤ ④ ⑤ ⑤ ② ⑤ ④
② ⑤ ④ ⑤ ④ ⑤ ④⑤ ④⑤ ④ ③ ⑤ ② ③ ④
23
