Tomei Powered TECHNICAL TRAX/ ADVANCE LSD - Manual (Page 18)

POST INSTALLATION TEST
As with engines and brake pads, wearing/running in the LSD is required before full use is possible.
This will guarantee effective operation and prolong the LSD unit’s durability.
Neglecting this important procedure can result shortened wear life and malfunction.
[How to run in the LSD]
①Minimum turning radius (the steering wheel is on full lock) with 30 minutes repeatedly turning left
and right. As in the diagram, drive in a straight line and coast while turning.
②The next procedure is to travel 100km at the maximum speed of 60km/h or below.
・An oil change is required after the initial run in to flush any unwanted material.
・A Periodic oil change is required at every 3000km.
・When strange noise (chattering sound) becomes louder is the sign for an oil change.
・If you feel realize something abnormal whilst driving (extremely strange noise, vibration and/or damage)
best to stop driving immediately and to do a full overhaul to inspect everything. If you risk to continue,
the results can lead to a breakdown or/and accident which can result in hazardous consequences.
Whilst turning, disengage the
clutch and turn whilst coasting.
In the straight line section best to stay in 1st gear and stay
at 20km/h or under.
Clockwise Anticlockwise
18
