Tomei Powered FUEL RAIL - Manual (Page 10)

REMOVING THE STOCK PARTS
■ Work with minimal amount of gasoline in the tank.
■ Use high-pressure air to clean any dust and debris before removing any parts.
■ Drain all remaining gasoline from the piping, remove the drain hose. Use the pan
and rage to catch any spillages.
■ Use duct tape to block/cover any holes to prevent anything from entering the
engine after removing parts.
(1) Remove all gasoline from the fuel lines.
The procedure described here is a simple removal process. Refer to the workshop service manual
for more detailed information.
① Remove the rear seats.
② Remove the service hole cover and gasket.
③ Disconnect the Fuel Pump connector.
④ Start the engine, after it stalls, turn the key to the (OFF) LOCK position.
(2) Disconnect the battery's negative terminal.
(3) Remove the stock fuel rail.
① Remove the injector connectors
10
③ Remove the Fuel Rail and
the parts that you will not use.
② Remove
10
