Tomei Powered TITANIUM MUFFLER - Manual (Page 7)

4. Attach the silencer rubber to the silencer band and be careful not to damage anything when installing
the exhaust to the hanger mount.
* Use the included rubber silencer band (above⑧&⑨)
5. Take care with the clearances when fitting each part and installing the bolts from the front.
Supplied M12 bolt torque specs (previous page ⑤) [56 ~ 94N · m (5.7 ~ 9.6kgf-m)]
Supplied clamp band torque specs (previous page ⑦) [25N・m(2.6kgf-m)]
Supplied bolts M8 torque specs (previous page ⑩) [20~28N・m(2.0~2.9kgf-m)]
6. Attach the main pipes A/B with the main pipe B silencer assembly with the use of the springs.
* Included springs (previous page⑥).
CAUTION!
· Please check all clearances with the vehicles body and make sure that the bolts are not interfering
with anything else. The clearances can change from vehicle to vehicle. Be sure that all the bolts are
tightened correctly so that there is no pollution caused form any exhaust leaks.
· After fitting the straight pipe and/or catalytic converter please check that there are no signs of oil,
dirt so as not to burn them later when the car is running.
7. If needed you can then install the sound reducer.
* Use the sound reducer M6 button bolts (previous page⑫/⑬).
Torque Specs [8~12N・m (0.8~1.2kgf-m)]
WARNING
* It is highly recommended not to use the sound reducer when
using the car for high speed/ hard driving as it may cause
engine failure.
* Only install or remove the sound reducer when the engine and exhaust is cold to avoid any burns
or injuries.
8. Reconnect the cars battery negative terminal.
INSTALLATION VERIFICATION
1. Check again the vehicle that there are no parts interfering with any other components.
2. Start the engine and let it idle first before taking it up to 2500 RPM to check and listen for any signs
of exhaust leaks or any abnormal sounds. Then recheck the car again for any loose parts or gas leaks.
3. After the initial test drive check the car again for any signs of exhaust gas leakage and any loose
parts, bolts and nuts.
WARNING
· Any interference with any parts/components can pose a fire risk hazard so please meticulously check
the car after the install.
· Any exhaust leaks can decrease performance efficiency and also pose a health risk hazard with toxic
exhaust gas poisoning.
· If there is anything felt abnormal when driving please stop immediately and check the car over.
· When any work or checks are to be done with the metal exhaust components then please do so when
it is cold to prevent any burns and injuries.
· If any parts are lost or have fallen off then does not restart the car until the missing part(s) can be
replaced properly.
7
