9
3. Connect the temporary joint of the support pipe to a turbocharger by using a gasket.
(Use a supplied gasket: Ref previous page ①)
4. Fix the gasket onto the cylinder head and the Exhaust Manifold temporarily. (Use a supplied gasket: Ref previous page ②)
5. Insert a gasket into a Exhaust manifold and a Support pipe and fix Exhaust manifold and a Support pipe.
(An attached gasket: Previous page ② use)
6. Completely tighten the Exhaust Manifold. 【Tightening torque:T=30N・m(3.1kgf-m)】
7. Completely tighten the Support pipe. 【Tightening torque:T=35N・m(3.6kgf-m)】
8. When the stock Exhaust Manifold was removed, return the circumference part that was removed simultaneously.
9. Reconnect the battery's negative terminal.
CAUTION
Remove any dirt and grime when using it with oil etc. check your exhaust manifold and the support pipe.
To remove any unwanted material after the installation.
4. INSTALLATION VERIFICATION
1. Double check to ensure all work is completed well and that there is no interference with any parts or wirings with
the Exhaust Manifold and Suport pipe.
2. Start the engine and confirm that there is no signs of any exhaust leakage.
CAUTION
If the Bandage that is wrapped around the manifold is heated up by the vehicle exhaust emission, it can emit
smoke for short periods until it is bedded in.
WARNING
・Inhaling exhaust over a short period of time will cause injury. Please make sure your working area is well
ventilated.
・Make sure no obtrusive objects are in the way during engine running.
Confirm whether to interfere with neither parts nor peripheral wirings in Exhaust Manifold.
