9
2．TOMEI TURBO SUCTION HOSE INSTALLATION
1 Detach the 2 nipples from the body that are circled below.
(Twist to remove them with ease. Take care not to use excessive force, as doing so can damage
the product.)
Before Removal After Removal
2 Carefully feed the silicone hose in the gap between the intake manifold and engine. If required,
use lubricant (like WD40) to help with installation.
3 Then return all parts in the same way that you had removed the stock suction pipe. If required, you can
again apply a small amount of lubricant.
4 A degreasing lubricant agent should be used when applying to the intake manifold area. Take care when
using the degreasing agent on the hose.
5 Attach the nipples that were removed earlier. (Can be split into 2 elbow nipples)
Attach the body to the suction side and temporarily keep the hose band in place. Install the hose in a
horizontal direction. Apply thread lock paste on the screws when installing the hose.
6 Use the hose bands to hold the nipples in place.
Apply Thread Lock Paste
