8
1. REMOVING THE STOCK ITEM
The procedure is described here are simple instructions. Refer to the workshop service manual for
more detailed information.
1 Disconnect the battery's negative terminal connector.
2 Remove the air intake guide & the alternator belt cover.
v
3 Remove the strut tower bar.
4 Remove the intercooler.
5 Remove all 5 hoses that are attached to the stock suction hose hoses band.
6 Cut off the stock suction pipes protruding bits that are connected to the stock blow off valve return.
※ The stock suction pipe
cannot be used again.
7 Remove the stock suction pipe by extracting it from the intake manifold.
CAUTION
The process that's shown above is for removing the stock item. Do not re-use the above stock
suction pipe. The process described here is the easy installation process for this product. If
you want to re-use the stock suction pipe later, refer to the workshop service manual as the
intake manifold will need to be removed.
Cut these protuding
parts to allow
removal.
