(3) CRANKSHAFT BLIND SCREW INSTALLATION
The Crankshaft must be thoroughly cleaned prior to installation. All signs of unwanted debris
and residue must be removed from the Crankshaft and the PT 1/16 blind screws (included
in the kit). Then install the blind screws in the Crankshaft, as shown in the illustration above,
at points numbered #1-4. Use thread lock paste on the screws to prevent it from coming loose.
※ If the Blind Screws aren't done up correctly, there will be a risk of oil leak, and or the Screw
coming loose, which can cause terminal engine failure.
※The Blind Screws must not protrude from the surface of the Crankshaft.
①
②
④
⑤
