Index Recommended
No. Description Part No. For 10 Units
1. Dual Regulator, Pressure Building/Economizer 8816-1060 2 Each
400 psig (28 bar/2758 kPa) - for XL-50VHP Only
Dual Regulator, Pressure Building/Economizer 6999-9018 2 Each
300 psig (20.9 bar/2068 kPa)
Dual Regulator, Alternate, Pressure Building/Economizer 6999-9015 2 Each
125 psig (8.6 bar/862 kPa)
- Not available for C0
2
service
2. Gasket, Glass Filled Teflon, Contents Gauge (Not Shown) 7701-0083 5 Each
3. Contents Gauge Assembly (Includes Gauge and Spring) GL50-9C40 1 Each
* Float Rod (45HP/50HP/50VHP) 1700-9C60 1 Each
(55HP) BC04-9C60 1 Each
(Use GL50-9C25 for nitrous oxide service)
4. Contents Gauge Cover, Protective Clear GL50-9C04 4 Each
Contents Gauge Cover, Nitrogen GL50-9C15 4 Each
Contents Gauge Cover, Oxygen GL50-9C16 4 Each
Contents Gauge Cover, Argon GL50-9C17 4 Each
Contents Gauge Cover, Carbon Dioxide GL50-9C18 4 Each
(Use GL50-9C04 for nitrous oxide with the contents
scale HP50-9C44.)
5. Screw, Brass 1/4 in. - 20 UNC x 5/8 in. 6114-1087 10 Each
6. Gauge, Pressure 0-600 psig (0-41 bar/0-4137 kPa) 1706-9C14 2 Each
7. Safety Head 525 psig (36 bar/3620 kPa) 1705-9C12 2 Each
Safety Head 750 psig (52 bar/5171 kPa) - for XL-50VHP Only 7815-3085 2 Each
8. Relief Valve
500 psig (34 bar/3447 kPa) - not for C0
2
- for XL-50VHP Only 6913-9061 2 Each
500 psig (34 bar/3447 kPa) - for C0
2
- for XL50VHP Only 6913-9062 2 Each
350 psig (24 bar/2413 kPa) - not for C0
2
or N
2
0 1705-9C39 5 Each
350 psig (24 bar/2413 kPa) - for C0
2
or N
2
0 1706-9C12 5 Each
**22 psig (1.5 bar/152 kPa) - not for C0
2
or N
2
0 6913-6223 5 Each
**230 psig (16 bar/1586 kPa) - not for C0
2
or N
2
0 1700-9C39 5 Each
9. Valve Repair Kit 1750-9C35 3 Each
10. Elbow, Male, Brass 45 ° 3/8 in. ODT-comp x 1/4 in. 6814-9233 2 Each
11. Connector, Male, Brass, 3/8 in. ODT-comp x 1/4 in. NPT-EXT 4570-1960 2 Each
12. Tube, P.B./Economizer Line GL45-9C20 2 Each
13. Cross, Brass GL55-9C30 2 Each
14. Elbow, Male, 3/8 in. NPT x 1/4 in. NPT 45 ° 6814-9241 2 Each
End Fittings for Hand Valves
15. -USE (CGA 540) -oxygen 7114-0163 5 Each
-USE (CGA 580) -argon/nitrogen 7114-0164 5 Each
-USE (CGA 320) -carbon dioxide 7114-0181 5 Each
-USE (CGA 326) -nitrous oxide 7114-0195 5 Each
16. -LIQUID (CGA 440) -oxygen 6514-8992 5 Each
-LIQUID (CGA 295) -argon/nitrogen 7355-4712 5 Each
-LIQUID (CGA 320) -carbon dioxide 7114-0181 10 Each
-LIQUID (CGA 326) -nitrous oxide 7114-0195 10 Each
25
