MAINTENANCE INSTRUCTIONS
For efficient and safe operation and to extend the life of your
heater it should be cleaned and inspected for damage at least
annually (preferably at the beginning of the heater season) or
more often in dirty environments. Other than cleaning, your
heater requires no other preventative maintenance. The user
can perform some basic cleaning of the heater. All other servic-
ing is to be done by qualified service personnel.
1. Heater cabinet may be cleaned using a damp cloth to
remove dust that may have accumulated on surfaces. Do
not use harsh cleaners and waxes on surfaces since these
could damage the finish or discolor in use.
2. A vacuum cleaner and /or compressed air may be used to
remove dust and lint that may have accumulated inside
heater around element fins. If heater must be dissembled for
cleaning, use care when cleaning element fins to avoiding
damaging fins.
3. After cleaning and servicing, reassemble by replacing any
hardware removed and check unit to make sure it are oper-
ates properly.
THERMAL SAFETY SWITCH: Your heater is provided with an
automatic-resetting thermal safety switch that will disconnect
power to the heating element should the heater be placed into
an abnormal condition (such as a blockage) to prevent a fire.
When the heater cools, the safety switch will reset allowing the
heater to return to normal operation.
TO PREVENT A POSSIBLE ELECTRIC SHOCK, ALWAYS
UNPLUG HEATER FROM OUTLET BEFORE CLEANING OR
SERVICING.
ALLOW HEATER TO COOL BEFORE CLEANING TO
PREVENT A POSSIBLE BURN.
FINS ARE SHARP AND MAY CAUSE CUTS SO AVOID
CONTACT.
3
Figure 2 – Repair Parts
Repair Parts List for Portable Electric/Hydronic Baseboard Heater
3
2 1 L O O F F H I
1
2 3
4
5
Reference
Number
Description Part Number Quantity
1 Pilot Light 3510-2006-000 1
2 Diode 1610-2002-000 1
3 Thermostat 5813-2019-000 1
4 Knob 3301-2011-001 1
5 Switch 5216-2007-000 1
