RENEWAL PARTS IDENTIFICATION

Parts Common to Wall and Pole Mounting Kits

Parts Common to PMB Mounting Kits Only

Parts Common to Ceiling Mounting Kit

Parts Description

XWM-12, XPM-12 — 12” Fan (3-10 kW)

XWM-16, XPM-16 — 16” Fan (15-20 kW)

XWM-20, XPM-20 — 20” Fan (25-35 kW)

Mounting Bracket

027-302359-004

027-302359-005

027-302359-006

Adapter Bracket

027-302361-001

027-302361-002

027-302361-003

1” Swivel Mount Bolt

345-075604-326

1” Swivel Mount Nut

200-075473-146

1” Swivel Mount Flat Washer

328-024326-045

5/8” Adapter Bolt

345-075604-045 (2)

5/8” Adapter Lock Washer

328-075571-019 (2)

1” Swivel Mount Lock Washer

328-075571-023

XPM-12, 12” Fan (3-10 kW)

Parts Description

XPM-16, 16” Fan (15-20 kW)
XPM-20, 20” Fan (25-35 kW)

Pole Support Bracket

027-302362-001

Pole Support Base

015-302363-001

Parts Description

XCMOB 12”, 16”, and 20” Fan

Hanger Bracket

027-320360-001(4)

Hanger Turnbuckle

140-302379-001 (2)

Cross Bolt

”

345-075603-335 (2)

Cross Bolt Nut

”

200-075473-056 (2)

Cross Bolt Lock Washer

328-075571-013 (2)

” Lock Nut

328-075571-019 (4)

” Hex Nut

200-075473-129 (4)

All products manufactured by Marley Electric Heating are warranted against defects in workmanship and

materials for one year from date of installation. This warranty does not apply to damage from accident, mis-
use, or alteration; nor where the connected voltage is more than 5% above the nameplate voltage; nor to
equipment improperly installed or wired or maintained in violation of the product’s installation instructions.
All claims for warranty work must be accompanied by proof of the date of installation.

The customer shall be responsible for all costs incurred in the removal or reinstallation of products, includ-
ing labor costs, and shipping costs incurred to return products to Marley Electric Heating Service Center.
Within the limitations of this warranty, inoperative units should be returned to the nearest Marley autho-
rized service center or the Marley Electric Heating Service Center, and we will repair or replace, at our
option, at no charge to you with return freight paid by Marley. It is agreed that such repair or replacement
is the exclusive remedy available from Marley Electric Heating.

THE ABOVE WARRANTIES ARE IN LIEU OF ALL OTHER WARRANTIES EXPRESSED OR IMPLIED. AND ALL

IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE WHICH
EXCEED THE AFORESAID EXPRESSED WARRANTIES ARE HEREBY DISCLAIMED AND EXCLUDED FROM
THIS AGREEMENT. MARLEY ELECTRIC HEATING SHALL NOT BE LIABLE FOR CONSEQUENTIAL DAM-
AGES ARISING WITH RESPECT TO THE PRODUCT, WHETHER BASED UPON NEGLIGENCE, TORT, STRICT
LIABILITY, OR CONTRACT.

Some states do not allow the exclusion or limitation of incidental or consequential damages, so the above
exclusion or limitation may not apply to you. This warranty gives you specific legal rights, and you may also
have other rights, which vary, from state to state.

For the address of your nearest authorized service center, contact Marley Electric Heating in Bennettsville,
SC, at 1-800-642-4328. Merchandise returned to the factory must be accompanied by a return authoriza-
tion and service identification tag, both available from Marley Electric Heating. When requesting return
authorization, include all catalog numbers shown on the products.

LIMITED WARRANTY

470 Beauty Spot Road, E
Bennettsville, SC 29550 USA

PPD031

5200-2474-000

How to order repair parts:
In order to obtain any needed repair or replacement parts,
warranty service or technical information, please contact
the Marley Electric Heating Service Center toll-free by
calling 1-800-642-HEAT.
When ordering replacement parts, always give the infor-
mation listed as follows:

The Part Number

The Model Number

The Part Description

Date of Manufacture
