11

3, 5,

7.5 &10

15 &18

25, 30 & 35

Item#

Description

Part No.

Part No.

Part No.

1

Panel wrapper

207-303891-001

207-303891-002

207-303891-003

6

Panel Bottom

207-303881-001

207-303881-002

207-303881-003

8

Panel Front

207-303883-001

207-303883-002

207-303883-003

9

Louver

182-303884-001

182-303884-002

182-303884-003

10

Washer Shoulder

328-302074-002

328-302074-002

328-302074-002

12

Spring

276-130386-001

276-130386-001

276-130386-001

14

Terminal Box Cover

080-302079-001

080-302079-001

080-302079-001

15

Screw 10-32

248-073662-002

248-073662-002

248-073662-002

16

Fan Blade

Consult Factory

Consult Factory

Consult Factory

17

Fan Guard

134-302063-004

134-302063-005

134-302063-006

25

Enclosure

347-123273-131

347-123273-131

347-123273-131

26

Bolt 3/8-16, 1.5 lg

345-075603-263

345-075603-263

345-075603-263

27

Washer flat

328-075528-085

328-075528-085

328-075528-085

28

Washer lock

328-075571-011

328-075571-011

328-075571-011

29

Hex Nut 3/8-16

200-075473-044

200-075473-044

200-075473-044

30

Plug conduit 1/2"

221-302180-001

221-302180-001

221-302180-001

31

Plug conduit 1"

221-302180-003

221-302180-003

221-302180-003

32

Union conduit 3/4"

354-302165-001

354-302165-001

354-302165-001

33

Union conduit 3/4"

354-302243-001

354-302243-001

354-302243-001

34

Conduit Box

Consult factory

069-304115-002

069-304115-002

35

Conduit 3/4"

Consult factory

Consult factory

Consult factory

44

Plug conduit 3/4"

221-302180-002

221-302180-002

221-302180-002

50

Bolt 5/16-18

345-075603-218

345-075603-218

345-075603-218

51

Washer

328-075571-010

328-075571-010

328-075571-010

52

Nut 5/16-18

200-075473-039

200-075473-039

200-075473-039

62

Cover Exp. Proof

080-042350-007

080-042350-007

080-042350-007

75

Conduit 3/4

069-115087-049

069-115087-079

069-115087-093

1/4 HP

Motor

Heat Exchanger*

Model

Item 19

Item 49

X300812B

193-302087-006

353-304167-001

X300832B

193-302087-007

353-304167-001

X300412B

193-302087-006

353-304167-002

X300432B

193-302087-007

353-304167-002

X3004832B

193-302087-007

353-304167-005

X300632B

193-302087-008

353-304167-006

X500812B

193-302087-006

353-304167-008

X500832B

193-302087-007

353-304167-008

X500412B

193-302087-006

353-304167-009

X500432B

193-302087-007

353-304167-009

X5004832B

193-302087-007

353-304167-012

X500632B

193-302087-008

353-304167-013

X750812B

193-302087-006

353-304168-001

X750832B

193-302087-007

353-304168-001

X750412B

193-302087-006

353-304168-002

X750432B

193-302087-007

353-304168-002

X7504832B

193-302087-007

353-304168-005

X750632B

193-302087-008

353-304168-006

X1000832B

193-302087-007

353-304168-008

X1000412B

193-302087-006

353-304168-009

X1000432B

193-302087-007

353-304168-009

X10004832B

193-302087-007

353-304168-012

X1000632B

193-302087-008

353-304168-013

X1500832B

193-302087-007

353-304169-001

X1500432B

193-302087-007

353-304169-002

X15004832B

193-302087-007

353-304169-005

X1500632B

193-302087-008

353-304169-006

X1800432B

193-302087-007

353-304169-008

X20004832B

193-302087-007

353-304169-012

X2000632B

193-302087-008

353-304169-013

1/2 HP Motors

X25004832B

193-302087-009

353-304170-003

X2500632B

193-302087-010

353-304170-004

X30004832B

193-302087-009

353-304170-008

X3000632B

193-302087-010

353-304170-009

X35004832B

193-302087-009

353-304170-012

X3500632B

193-302087-010

353-304170-013

Common Parts

Motor, Element and Heat Exchanger Parts

Shown in Figure 17

Optional Equipment Parts

Description

Part Number

Thermostat

300-113075-003

15 Amp Disconnect - 3PH

104-304328-003

30 Amp Disconnect - 1PH

104-304328-004

30 Amp Disconnect - 3PH

104-304328-001

60 Amp Disconnect

104-304328-002

Pilot Light Ass’y 24V

213-121103-017

Pilot Light Ass’y 120V

213-121103-018

Pilot Lamp 24V

172-052561-004

Pilot Lamp 120V

172-052561-003

* For arctic duty conditions, heat exchanger with ethylene

glycol are required. Consult factory.

Mounting Kit Adapter

3 through 10

027-302361-001

15 through 20

027-302361-002

25 through 35

027-302361-003

The factory must perform the
replacement of the immersion heater
or overtemperature cutout. The heat
exchanger seal must not be broken.
Consult factory for service.

RENEWAL PARTS IDENTIFICATION
