MOUNTING KITS
Figure 5
Figure 7
Figure 9
Figure 6
Figure 10
Wall Mount Kit
Model # XMB-12 12” Fan (3-10 kW)
Model # XMB-16 16” Fan (15-20 kW)
Model # XMB-20 20” Fan (25-35 kW)
Pole or Wall Mount Kit
Model # XPM-12 12” Fan (3-10 kW)
Model # XPM-16 16” Fan (15-20 kW)
Model # XPM-20 20” Fan (25-35 kW)
Ceiling Mount Kit
Model # XCMOB
P
12” Fan - 16-3/4”
16” Fan - 18-1/2”
20” Fan - 22”
Wall
Bracket
1”ø Hardware % Bolt
Single Point
Swivel Mount
Supplied
1/2 ø Hardware
Not Supplied
Adapter Bracket
& 5/8 NC Hardware
Supplied
5-1/2” - 12” Fan
5-1/8” - 16” Fan
6-3/8” - 20” Fan
3 through 10 kW P=10”
15 through 20 kW P=11-1/2”
25 through 35 kW P=14-1/2”
4-7/8
4-9/16
Swivel Ceiling
Hanger S/A &
Hardware
5/8” ø Hex
Nuts & Washers
Cust. Supplied ø 1/2 Mounting
Hardware. Bracket Spacing
suitable for use with 4” U-Bolts
Supplied for
Installation
Top & Bottom
ø 5/8 Rods Length to
suit 1” Min. Threaded
Ends Customer Supplied
Pole Base
➀
3/8” ø Hardware
Required for
Mounting -
Cust. Supplied
6” Ref.
3-1/2” SCH. 40 Pipe
or 4” O.D. X .25 Wall
Tube Cust. Supplied
Length to Suit
P
Adapter Bracket
Supplied
with 5/8 Bolts
Single Point
Swivel 4”ø
Supplied
➂
➁
Pole Support
Bracket
Heater Mounting
Bracket Arm &
Hardware
ø 3/8 Hardware
Cust. Supplied
ø 1/2 x 4” U-Bolts
& Hardware
Cust. Supplied
5/8-11 Threaded
Mounting Holes (2)
1/2” NPT
Thermostat Entry
1” NPT
Top Line Supply
Entry
Unit Top View Electrical
Components
Pilot Lamp (Opt.)
Transformer
1” NPT
Jumper Wire
Contactor
Heat
Exchanger
Wiring
Compartment
3 through 10 kW P=10”
15 through 20 kW P=11-1/2”
25 through 35 kW P=14-1/2”
