CY7C1161V18, CY7C1176V18
CY7C1163V18, CY7C1165V18

Document Number: 001-06582 Rev. *D

Page 24 of 29

DLL Timing

t

KC Var

t

KC Var

Clock Phase Jitter

0.20

0.20

0.20

0.20

ns

t

KC lock

t

KC lock

DLL Lock Time (K)

2048

2048

2048

2048

Cycles

t

KC Reset

t

KC Reset

K Static to DLL Reset

[30]

30

30

30

30

ns

Switching Characteristics

Over the operating range

[23, 24]

(continued)

Cypress

Parameter

Consortium

Parameter

Description

400 MHz

375 MHz

333 MHz

300 MHz

Unit

Min

Max

Min

Max

Min

Max

Min

Max

Note

30. Hold to >V

IH

or

IL

.
