92

Appendix

w

w

w

.d

e

ll

.co

m

|

s

u

p

p

o

rt

.d

e

ll.c

o

m

Ports and Connectors

(continued)

Internally accessible:

Primary IDE channel

40-pin connector on PCI local bus

Secondary IDE channel

40-pin connector on PCI local bus

Floppy drive

34-pin connector

Audio

3

Audio controller

Analog Devices AD1885 AC97 Codec

Video
Video controller

AGP 4X

Controls and Lights
Power control

push button

Power light

green light on power button—blinking green

in sleep state; solid green for power on state

Hard-drive access light

green

Diagnostic code lights

four bicolor (amber and green) located on

back panel

Power
DC power supply:

Wattage

250 W

Heat dissipation

534 BTU (fully-loaded computer without

monitor)

Voltage (switch-selectable

on back panel)

90 to 135 V at 50/60 Hz;180 to 265 V at 50/60

Hz;100 V at 50/60 Hz for Japanese computers

Backup battery

3-V CR2032 coin cell

3

Present only on computers with built-in audio capabilities
