94 Installing System Components
1 Turn off the system and attached peripherals, and disconnect the system
from the electrical outlet.
2 Open the system. See "Opening the System" on page 50.
3 Remove the cooling shroud. See "Removing the Cooling Shroud" on
page 67.
4 Remove any expansion card. See "Removing an Expansion Card" on
page 61.
5 Remove the processor heat sink. See "Removing a Processor" on page 82.
6 If installed, remove the iDRAC6 Enterprise card. See "Removing an
iDRAC6 Enterprise Card" on page 81.
7 If installed, remove the iDRAC6 Express card. See "Removing an iDRAC6
Express Card" on page 78.
8 Disconnect all cables from the system board.
9 Remove all the memory modules and memory blanks. See "Removing
Memory Modules" on page 73.
NOTE: To ensure proper reinstallation of memory modules, record the
memory module socket locations.
10 Remove the ten screws securing the system board to the chassis and then
slide the system board assembly toward the front end of the chassis.
CAUTION: Do not lift the system board assembly by grasping a memory module,
processor, or other components.
11 Grasp the system board assembly by its edges and lift the assembly away
from the chassis. See Figure 5-21.
