Using the System Setup Program and Boot Manager 45
iDRAC6 Configuration Utility
The iDRAC6 Configuration Utility is a pre-boot configuration environment
that allows you to view and set parameters for the iDRAC6 and for the
managed server.
The iDRAC6 Configuration Utility provides the following features:
• Enables fault logging and SNMP alerting
• Provides access to system event log and sensor status
• Allows control of system functions including power on and off
• Functions independently of the system’s power state or the system’s
operating system
• Provides text console redirection for system setup, text-based utilities, and
operating system consoles.
In addition, the iDRAC6 Configuration Utility enables you to:
• Configure, enable, or disable the iDRAC6 local area network through the
dedicated iDRAC6 Enterprise card port or the embedded NIC1.
• Enable or disable IPMI over LAN.
• Enable a LAN Platform Event Trap (PET) destination.
• Attach or detach the Virtual Media devices.
• Change the administrative user name and password and manage user
privileges.
• View System Event Log (SEL) messages or clear messages from the log.
For additional information on using iDRAC6, see the documentation for
iDRAC6 and systems management applications at
support.dell.com/manuals.
Entering the iDRAC6 Configuration Utility
1 Turn on or restart your system.
2 Press when prompted during POST.
If your operating system begins to load before you press ,
allow the system to finish booting, and then restart your system and try
again.
