Installing System Components
41
Installing System Components
This section describes how to install the following system components:
• Front drive bezel
• Hard drives
• Diskette drive
• Optical and tape drives
• Expansion cards
• SAS controller card
• Microprocessor
• Memory
• System battery
• Power supply
• Cooling Fans
• Chassis intrusion switch
• Bezel
• Front I/O panel
• System board
Recommended Tools
You may need the following items to perform the procedures in this section:
• #2 Phillips screwdriver
• Long #2 Phillips screwdriver (blade at least 6 inches long)
• Needle-nose pliers
• Wire cutter (optional)
• Small flat-blade driver
• Wrist grounding strap
