Replacing the display panel
WARNING: Before working inside your computer, read the
safety information that shipped with your computer and
follow the steps in Before working inside your computer .
After working inside your computer, follow the instructions
in After working inside your computer . For more safety best
practices, see the Regulatory Compliance home page at
dell.com/regulatory_compliance.
Procedure
1 Slide the display cable into the display panel and press down on the latch
to secure the cable.
2 Turn the display panel over.
3 Align the screw holes on the display panel with the screw holes on the
display back-cover.
4 Replace the screws that secure the display panel to the display back-cover.
Post-requisites
1 Follow the procedure from step 2 to step 5 in “Replacing the display bezel ”.
2 Replace the display assembly .
3 Replace the hinge covers .
4 Follow the procedure from step 5 to step 11 in “Replacing the palm rest ”.
5 Replace the wireless card .
6 Replace the solid-state drives .
7 Replace the memory modules .
8 Replace the base panel .
