Appendix
95
Video type: discrete video card
Data bus PCI Express X16
Video controller ATI Mobility Radeon X300
Video memory 64 MB and 128 MB
LCD interface LVDS
TV support NTSC or PAL in S-video and composite
modes
Audio
Audio type AC’97 (Soft Audio)
Audio controller
Stereo conversion 18-bit (analog-to-digital and digital-to-analog)
Interfaces:
Internal PCI bus/AC’97
External microphone-in connector, stereo
headphones/speakers connector
Speaker two 4-ohm speakers
Internal speaker amplifier 1-W channel into 4 ohms
Volume controls keyboard shortcuts, program menus, media
control buttons
Audio controller Sigmatel STAC9751 AC’97 Codec
Display
Type (active-matrix TFT) 15.4-inch WXGA, WSXGA+, and WUXGA
Dimensions:
Height 222.5 mm (8.8 inches)
Width 344.5 mm (13.6 inches)
Diagonal 391.2 mm (15.4 inches)
Maximum resolutions:
WXGA 1280 x 800 at 16.7 million colors
WSXGA+ 1680 x 1050 at 16.7 million colors
WUXGA 1920 x 1200 at 16.7 million colors
Video (continued)
