6 Using the Baseboard Management Controller
ww
w
.
de
l
l
. co
m
|
s
u
pp
o
rt
. d
e
ll
. c
o
m
Watchdog and Automatic System Recovery
The BMC watchdog timer commands, as defined in the IPMI v2.0 specification, are part of
the Intelligent Platform Management Interface. The watchdog timer can restart, turn off,
or cycle power to your server in your absence to support automatic system recovery
functions. If a
pre-set interval expires, the configured timer actions are executed and logged into SEL for
later examination. The timer commands are:
• System reset
• System power off
• System power cycle
• Host diagnostic interrupt
NOTE: The software that acquired and activated the watchdog timer is responsible for resetting the
timer countdown.
Virtual Storage
The firmware supports USB diskette, keyboard, mouse, and CD/DVD. These are supported
as a composite device. The USB keyboard and mouse traffic is bridged to the KVM
connections.
Using the Web User Interface
The embedded console client provides KVM/IP functionality. The client is in the form of an
ActiveX control for the Windows
®
platform and an application for the Linux
®
platform.
NOTE: The application must be installed before completing the console redirection.
A web-based graphic user interface (GUI) is supported on the following browsers:
• Windows platforms: Internet Explorer
®
6.0 or later
• All platforms: Firefox 2.0017 or later
NOTE: Before using the Web user interface, ensure that the firewall settings are configured to enable
access to the following: KVM:7578, USB–CDROM:5120, and USB–Floppy:5123.
Logging into the Web User Interface
Enter the BMC-embedded server IP address or URL into the address bar of the web browser.
The BMC interface has a default of (DHCP\Static). Press the key to enter the system
BIOS setup and change these settings.
