Using the Baseboard Management Controller

VLAN ID

Use the LAN configuration command parameter 14H to set or get the VLAN ID. For
additional information, refer to the IPMI v2.0 specifications.

Table 1-61. VLAN Commands

Commands

NetFn

CMD

O/M

Supported

Set LAN Configuration
Parameters (Parameter 9 and 25 are not
supported)

Transport 01h

Yes

Get LAN Configuration
Parameters (Parameter 9 and 25 are not

supported)

Transport 02h

Yes

Table 1-62. LAN Configuration Parameter 14H

Parameter

Parameter Data

802. 1q VLAN ID (12-bit)

14H

Data 1

[7:0] — Least significant 8-bits of the VLAN ID. 00h if
VLAN ID not used.
Data 2
[7] — VLAN ID enable.
0b — Disabled
1b — Enabled
If enabled, the BMC will only accept packets for this
channel if they have 802.1q fields and their VLAN ID
matches the VLAN ID value given in this parameter.
[6:4] — Reserved
[3:0] — Most significant 4-bits of the VLAN ID

Examples:

Set VLAN ID:

• Get LAN configuration parameter:

ipmitool 0xC0 0x02 0x01 0x14 0x00 0x00
Response: 0x00 0x11 0x01 0x80 (VLAN Enable and VLAN ID: 1)

• Set LAN configuration parameter:

ipmitool 0xC0 0x01 0x01 0x14 0x01 0x80
Response: 0x00
