45 Using the Baseboard Management Controller
ww
w
.
de
l
l
. co
m
|
s
u
pp
o
rt
. d
e
ll
. c
o
m
Threshold Settings and Converting Formulas
Table 1-47. Threshold Settings and Converting Formulas
Sensor
Number Sensor Name The Converting Formula
Fan
Upper non-
recoverable Upper
critical Upper
non-critical Lower non-
recoverable Lower
critical Lower
non-critical
01h FCB FAN1 Actual_Reading (RPM) = Raw_Data x 100
0xFF 0xFF 0xFF 0x00 0x0F 0x00
02h FCB FAN2 Actual_Reading (RPM) = Raw_Data x 100
0xFF 0xFF 0xFF 0x00 0x0F 0x00
03h FCB FAN3 Actual_Reading (RPM) = Raw_Data x 100
0xFF 0xFF 0xFF 0x00 0x0F 0x00
04h FCB FAN4 Actual_Reading (RPM) = Raw_Data x 100
0xFF 0xFF 0xFF 0x00 0x0F 0x00
Voltage
14h
PS 12V Actual_Reading (Volts) = Raw_Data x 0.062
0xD8 0xD4 0xCF 0xAB 0xAF 0xB4
15h PS 5V Actual_Reading (Volts) = Raw_Data x 0.026
0xD7 0xD3 0xCD 0xA9 0xAE 0xB3
16h STBY 3.3V Actual_Reading (Volts) = Raw_Data x 0.0172
0xD6 0xD3 0xCD 0xA9 0xAD 0xB3
51h VCORE 1 Actual_Reading (Volts) = Raw_Data x 0.0083
0xFF 0xFF 0xFF 0x00 0x00 0x00
