260 Paper Jam Check Env Feeder

Envelope jams may occur in two areas.

NOTE:

To resolve the message, you must clear all envelopes from the print media path.

For instructions on clearing the jam, click the area where the jam occurred:

At entry into the envelope feeder

Between the envelope feeder and the printer

At entry into the envelope feeder

Since the envelope feeder feeds envelopes from the bottom of the stack, the envelope on the bottom is
jammed.

Lift the envelope weight.

1.

Flip the envelope weight back toward the printer.

2.

Remove the stack of envelopes from the envelope feeder.

3.

Slowly pull the jammed envelope straight out toward you.

4.

5.
