Dell Alienware M18x (Early 2011) User Manual
Page 56
5.
Replace the 11 screws that secure the system board to the computer base.
6.
Slide the optical drive cable into the connector on the system board and press down on the connector latch to secure the cable.
7.
Connect the speaker cable and the subwoofer cable to the respective connectors on the system board.
8.
Follow the instructions from
step 13
to
step 23
in
Replacing the System Board
.
Back to Contents Page
CAUTION:
Before turning on the computer, replace all screws and ensure that no stray screws remain inside the computer. Failure to do so may
result in damage to the computer.
