USER’S GUIDE
Ma
na
ge
d R
a
ck
PD
U
14
10/100 LED
Condition Description
Off One or more of the following situations exists:
• The Rack PDU is not receiving input power.
• The cable that connects the Rack PDU to the network is
disconnected or defective.
• The device that connects the Rack PDU to the network is
turned off.
• The Rack PDU itself is not operating properly. It may need to
be repaired or replaced.
Solid green The Rack PDU is connected to a network operating
at 10 Megabits per second (Mbps).
Solid orange The Rack PDU is connected to a network operating
at 100 Mbps.
Flashing Green The Rack PDU is receiving or transmitting data packets
at 10 Mbps.
Flashing Orange The Rack PDU is receiving or transmitting data packets
at 100 Mbps.
