Adding and Replacing Parts 107
NOTICE: If you need to install memory modules in two connectors, install a
memory module in the connector labeled “JDIM (DIMMA)” before you install
a module in the connector labeled “JDIM2 (DIMMB).”
8 Ground yourself and install the new memory module:
HINT: If the memory
module is not installed
properly, the computer
does not boot. No error
message indicates this
failure.
a Align the notch in the module with the slot in the center of the
connector.
b Slide the edge of the module firmly into the connector, and rotate
the module down until you feel a click. If you do not feel the click,
remove the module and reinstall it.
9 Replace the cover and screw(s).
NOTICE: If the memor y module cover is difficult to close,
remove the module and reinstall it. Forcing the cover to close
may damage your computer.
memory
module
securing
clip
