About Your System 17
Power and System Board Status Codes
The LEDs on the system front and back panel display status codes during
system startup. All systems share the same LEDs on the front and back panel.
Table 1-6 lists the status associated with the codes.
Table 1-6. Power and System Board Indicator Codes
Table 1-7. System Identification Indicators
Table 1-8. Power Indicator Codes
Power-On Indicator Condition
Steady green, amber off Power is on.
Green off, blinks amber iBMC critical condition event in power
off mode (S4/S5).
Green, blinks amber iBMC critical condition event in power
on mode (S0/S1).
System Identification Indicator Condition
Steady blue IPMI OEM command is set.
Option on Web is chosen.
Blinks blue Identify button is pressed.
IPMI chassis Identified command is executed.
S3 Mode (4s/1s Interval).
Blinks blue continuously (four
seconds on/off
Power event in power standby mode (S3).
Blue off Turned off by IPMI chassis identify command
or ID button press identification off.
Power Indicator Condition
Steady green Power is on.
Steady yellow Power supply faulty
(UVP/OVP/OCP/SCP/OTP/Fan Fault).
