Removing the fan module – Dell PowerEdge C2100 User Manual
Page 101
Installing System Components
97
Removing the Fan Module
Remove the four screws that secure the fan module to the fan assembly and
separate the fan module from the fan assembly. See Figure 3-23.
Figure 3-23. Removing and Installing the Fan Module
1
cooling fans (3)
2
fan assembly
3
screws (4 each)
4
air flow direction
1
2
3
4
book.book Page 97 Friday, November 8, 2013 11:29 AM
