24

Tower-to-Rack and Rack-to-Tower Conversion Guide

www

.dell.com | support.dell.com

Figure 1-13.

Installing the Tower Trim Panel and Metal Feet

Removing the Bezel and Cover

1

To remove the bezel, perform the following steps:

a

Orient the system as shown in Figure 1-14.

b

Unlock the keylock. See Figure 1-14.

c

Rotate the keylock end of the bezel away from the front panel.

d

Unhook the other end of the bezel and pull the bezel away from the system.

trim panel

hex-head Phillips
screws (2)

hex-head Phillips
screws (2)

Y1001bk0.book Page 24 Thursday, July 8, 2004 4:32 PM
